Gallery

  • Simulated outgoing LW radiation at TOA for super-typhoon Saola 2023
  • Simulated wind and pressure for super-typhoon Saola 2023
  • Simulated outgoing LW radiation at TOA for super-typhoon Mangkhut using a customized 64-to-1 km mesh, initialized at 00 UTC 12 Sep 2018 by ERA5 reanalysis
  • Simulated outgoing LW radiation at TOA (rotating view) for super-typhoon Mangkhut using a customized 64-to-1 km mesh, initialized by ERA5 reanalysis
  • Close-up of simulated outgoing LW radiation at TOA for super-typhoon Mangkhut using a customized 64-to-1 km mesh, initialized by ERA5 reanalysis
  • Simulated wind and relative humidity at 500hPa for super-typhoon Mangkhut with HTS turned on
  • Simulated surface wind, precipitation rainfall, and MSLP for super-typhoon Mangkhut with HTS turned on
  • A customized 128-to-1km mesh over Geneva
  • Close-up of a customized Geneva_128-to-1km mesh over Geneva
  • Visualization of simulated 2m temperature of a customized 128-to-1km mesh using Jupyter Notebook Result Visualization
  • Full visualization of a customized mesh transitioning from 160km to 1km
  • Close-up of a customized mesh with refinement down to 1km, the mesh has smoothly-variation between coarse and fine mesh cells
  • Mesh resolution for a CPAS customized mesh, arbitrarily shaped regions are generated following users’ specifications
  • Distribution of time-step levels using the Hierarchical Time-Stepping (HTS) feature based on the size of mesh cells
  • Simulated temperature at 850hPa over Europe with HTS turned on
  • Simulated relative humidity at 700hPa over Australia with HTS turned on
  • Simulated 2m temperature over Western Asia with HTS turned on
  • Simulated radar reflectivity at 1km height over Southern China with HTS turned on
  • Simulated precipitable water over North America with HTS turned on
